Machine Parameters
| machine model | JC-1224-1000w | jc-1224-1500w | jc-1224-2000w |
| power | 1000w | 1500w | 2000w |
| the table moving | gantry construction | ||
| X-axis travel-length | 1200mm | ||
| Y-axis travel-length | 2400mm | ||
| cutting speed | 65-85m/h | 120-140m/h | 160-180m/h |
| Re-Positioning Precision | ≤0.02mm | ||
| 0.45mm, 0.71mm, 1.05/1.07mm at one time (die board) | 0.45mm, 0.71mm, 1.05/1.07mm at one time (die board) | ||
| controlling system | Germany PA | ||
| Transmission system | Ball screw & Linear guide (TAIWAN) | ||
| Driving system | Japan high-precision servo motors | ||
| Optical system | US | ||
| Moving structure | Gantry | ||
| Chiller system | Made in China | ||
| Size | 4800*2300*2300mm | ||
| G. Weight | 4200kgs | ||
| Laser generator gas matched | He, N2, CO2(99.999%) | ||
| Laser cutting thickness | 0.1-30mm | ||
| Centrifugal blower | 1 set | ||
Features and Functions
PA laser dedicated CNC system, laser and machine control system into one
The machine is equipped with CAD/CAM dedicated automatic programming software which is to facilitate the production of graphics programming and maximize the conservation of raw materials, and special cutting process features
The machine uses fully-enclosed cover, the effect of removing smoke is very good, 100% no smoke left in the workshop when cutting
The machine with enclosed optical path, use positive pressure to remove the dust, which can ensure the lens life
Stainless steel plate cover, can bear at least two weighted 80kg men standing on it, no deformation
Quick marking function is optional
New laser head design with anti-collision system two separated pressing feet with balls on the bottom, make sure moving smoothly
Gantry type machine can individually adjust 45, 90, 135 and whole X direction cutting kerf tightness. X,Y, Z axis individually control.
Auto oiling system
Cutting path display
High energy savings one bottle
Helium gas can be used for 300hours
